How to Choose the Right Pixel Pitch for an Indoor LED Screen

Choosing the right pixel pitch is one of the most important decisions when buying an indoor LED screen. It affects image quality, viewing comfort, and cost.

  • Too small pixel pitch → you pay more than needed
  • Too large pixel pitch → the screen looks pixelated

This guide helps you choose the right pixel pitch for your space, without overspending.

What Is Pixel Pitch?

Pixel pitch is the distance between two LED pixels, measured in millimeters.

Examples:

  • P2.5 = 2.5mm between pixels
  • Smaller number = sharper image
  • Larger number = lower resolution

Why Pixel Pitch Is Important

1. Image Quality

Smaller pixel pitch gives clearer and sharper images, especially when viewed up close.

2. Viewing Distance

Each pixel pitch has a minimum viewing distance.
If people stand closer than that, they will see individual dots.

3. Cost

Finer pixel pitch costs much more.

  • Choosing the correct pitch saves money

Simple Viewing Distance Rule

Minimum Viewing Distance (meters) = Pixel Pitch (mm)

Examples:

  • P2 → minimum 2 meters
  • P3 → minimum 3 meters
  • P4 → minimum 4 meters

Best (Comfortable) Viewing Distance

Usually 1.5–2 times the minimum distance.

Press enter or click to view image in full size
Indoor Pixel Pitch Categories

Ultra-Fine Pitch (P0.9 — P1.5)

Best for very close viewing (1–3m)

Used in:

  • Boardrooms
  • Control rooms
  • Broadcast studios
  • Luxury retail
  • Medical displays

✅ Extremely sharp
❌ Very expensive
💰 Cost: High

Fine Pitch (P1.6 — P2.5) ⭐ Most Popular Premium Choice

Best for 2–5m viewing

Used in:

  • Corporate meeting rooms
  • Retail stores
  • Hotel lobbies
  • Museums
  • Premium offices

✅ Great balance of quality & cost
💰 Medium–High cost
⭐ P2–P2.5 is the good.

Standard Pitch (P2.6 — P4) ⭐ Most Common

Best for 3–8m viewing

Used in:
  • Retail stores
  • Restaurants
  • Offices
  • Hotels
  • Event halls
  • Schools

✅ Best value for money
💰 Affordable
⭐ P3–P4 works for most indoor uses

Medium-Coarse Pitch (P5 — P6)

Best for large spaces (5–12m viewing)

Used in:

  • Auditoriums
  • Airports
  • Large malls
  • Big venues
  • Warehouses

✅ Lowest cost
❌ Not good for close viewing
💡 Usually the largest pitch used indoors

Press enter or click to view image in full size

How to Choose Pixel Pitch for Your Space

Step 1: Measure Viewing Distance

Measure from the screen to where people usually stand or sit.

Examples:

  • Meeting room: 3–4m
  • Retail store: 3–6m
  • Hotel lobby: 5–8m
  • Airport hall: 8–15m

Step 2: Match Pixel Pitch

Use this simple rule:

Press enter or click to view image in full size

Step 3: Consider Budget

Example for 10 sqm screen:

  • P2 → High cost
  • P3 → Medium cost
  • P4 → Lower cost

Tip: One step coarser often gives 90% quality at 70% cost

Step 4: Think About the Future

Choose slightly finer pitch if:

  • Viewing distance may reduce
  • Content may become more detailed
  • You want future-proof quality

Common Mistakes to Avoid

❌ Choosing cheapest option only
❌ Choosing ultra-fine pitch when not needed
❌ Ignoring content type
❌ Not planning for future use
❌ Using same pitch for all locations

Energy & Running Cost (Simple)

Smaller pitch = more LEDs = more power.

Over 10 years, choosing P4 instead of P2 can save thousands in electricity costs.

Why Choose DGICON?

At DGICON, we help you choose the right pixel pitch — not the most expensive one.

Our Process:

✔ Site visit & viewing distance check
✔ budget analysis
✔ Clear pitch comparison
✔ Honest recommendations
✔ Professional installation
✔ 3-year warranty & support

📍 Dubai, UAE
🌐 www.dgicon.com
📧 sales@dgicon.com

DGICON — Smart LED solutions. Right pixel pitch. Proven results.
